Brand   WABCO Original

Part Type   Premium original quality

Technical Specification   OE specification
Distance between bolts   70.0 mm
Max. operating pressure   8.5 bar
Port thread 1   M22 x 1.5 JED-152 / M16 x 1.5 JED-152
Port thread 11   M22 x 1.5 JED - 152 / M16 x 1.5 JED - 152
Port thread 21   M16 x 1.5 JED - 152
Port thread 22   M16 x 1.5 JED - 152
Port thread 23   M16 x 1.5 JED - 152
Port thread 24   M16 x 1.5 JED - 152
Port thread 32    Integrated Silencer
Port thread 4   M16 x 1.5 JED - 152
Port thread 42   M16 x 1.5 JED-152
Port thread 5   M16 x 1.5 JED-152
Protection Class   IP 6K9K
System   4S/3M
Temperature range   -40°C to +65°C
Type   Premium
Version   TEBS E with PEM
Voltage (V)   24 V
mounting   2x M12
Calculated Volume (dm³)   12.46
GTIN   7895851072213
Size (mm x mm x mm)   224 x 281 x 198
UPC   193133317173
Weight (kg)   6.234
Weight (lb)   13.74
