BrandWABCO Original
Part TypePremium original quality
Technical SpecificationOE specification
Distance between bolts70.0 mm
Max. operating pressure8.5 bar
Port thread 115 x 1.5 / 8 x 1
Port thread 1112 x 1.5 / 8 x 1
Port thread 2112 x 1.5
Port thread 2212 x 1.5
Port thread 238 x 1
Port thread 248 x 1
Port thread 32 Integrated Silencer
Port thread 48 x 1
Port thread 428 x 1
Port thread 58 x 1
Protection ClassIP 6K9K
System4S/3M
Temperature range-40°C to +65°C
TypePremium
VersionTEBS E with PEM
Voltage (V)24 V
mounting2x M12
Calculated Volume (dm³)36.2579
GTIN04057875228790
Size (mm x mm x mm)224 x 259 x 198
UPC193133317197
Weight (kg)6.2
Weight (lb)13.67
